Withdrawal Sleeves

Withdrawal sleeves are slit tapered sleeves that are used to mount bearings with a tapered bore onto the cylindrical seat of stepped shafts. This AH(X) sleeve has dimensions in accordance with ISO standards and is a basic design for mounting and dismounting. The sleeve is located on the shaft by a lock nut or an end plate.

Specifications:
Withdrawal sleeves # AH 2336 G,

170.00 mm Suitable Shaft Diameter,

M190X3 Thread Size,

KM 38 Removal Nut / HMV 38E Hydraulic Nut (nuts sold separately),

Series: AH,

Shaft Dia: mm 170.000,

Thread Size: M190X3,

Weight (Kg): 5.816,

Unit Of Measure: EA,
